D-Link NPP-C61BLK241 Cat6 24-Port Patch Panel (NPP-C61BLK241)

The D-Link NPP-C61BLK241 Cat6 24-Port Patch Panel is a professional-grade, fully loaded UTP patch panel designed for structured cabling systems in enterprise networks, offices, and data centers. Built for standard 19-inch rack installations, this 1U patch panel ensures organized cable termination, reliable Gigabit Ethernet performance, and long-term durability while supporting industry-standard wiring schemes and compliance requirements.

Product Features

24-Port Cat6 High-Performance Connectivity

The NPP-C61BLK241 features 24 pre-loaded RJ45 ports designed to support Cat6 Ethernet cabling with data transmission speeds of up to 1 Gbps and bandwidth up to 250 MHz. It is fully backward compatible with Cat5 and Cat5e cabling, ensuring flexibility in mixed network environments.

Standard 19-Inch Rack-Mount Design

Designed with a 1U form factor, this patch panel fits seamlessly into standard 19-inch server racks and network cabinets. Its compact layout helps optimize rack space while maintaining clear and accessible cable organization.

Durable Steel Construction

The panel is manufactured from high-quality SPCC cold-rolled steel and finished in a black RAL 9005 coating. This robust construction provides excellent mechanical strength and long-term durability in demanding network installations.

Flexible Termination with IDC Punch-Down

The rear IDC punch-down terminals support both 110 and Krone punch-down tools, allowing easy and secure cable termination. The panel supports solid and stranded wires ranging from 22 to 26 AWG.

Support for T568A and T568B Wiring Standards

Color-coded wiring labels enable quick and accurate termination using either T568A or T568B wiring schemes, ensuring compatibility with global cabling standards and simplifying installation.

Enhanced Cable Management and Identification

The NPP-C61BLK241 includes ID stripes and transparent designation labels for clear port identification. It is compatible with an optional rear cable management bar to reduce cable strain and improve airflow and overall rack organization.

Industry Standards Compliance

This patch panel meets key international cabling standards, including ANSI/TIA/EIA 568-C.2 and ISO/IEC 11801 Class E, ensuring consistent performance and interoperability across compliant network infrastructures.

Product Specifications

• Product Type: Cat6 UTP loaded patch panel
• Number of Ports: 24 RJ45 ports
• Connector Type: RJ45 8P8C
• Rack Compatibility: Standard 19-inch rack
• Rack Height: 1U
• Data Transmission Speed: Up to 1 Gbps
• Bandwidth: Up to 250 MHz
• Wiring Schemes: T568A and T568B supported
• Cable Compatibility: Cat6, backward compatible with Cat5 and Cat5e
• Termination Type: IDC punch-down terminals
• Tool Compatibility: 110 and Krone punch-down tools
• Supported Wire Gauge: 22 to 26 AWG solid and stranded
• Panel Material: SPCC cold-rolled steel
• Finish Color: Black RAL 9005
• RJ45 Contact Material: Phosphor bronze with nickel plating and 50 micro-inches gold plating
• Jack Durability: Minimum 750 mating cycles per port
• Operating Temperature Range: -10°C to 60°C
• Dimensions: 482.6 mm x 44.45 mm x 87.2 mm
• Weight: Approximately 1.2 kg to 2 kg
• Compliance Standards: ANSI/TIA/EIA 568-C.2, ISO/IEC 11801 Class E, UL, RoHS
• Additional Features: ID labeling stripes, transparent designation labels, optional rear cable management bar, integrated grounding terminal
