Tenda AC23 AC2100 Dual-Band Gigabit Wi-Fi Router

The Tenda AC23 AC2100 Dual-Band Gigabit Router is a powerful and reliable Wi-Fi solution designed for homes with high-speed fiber internet. Supporting the latest 802.11ac Wave 2.0 technology, it delivers blazing wireless speeds of up to 2033Mbps (2.4GHz: 300Mbps + 5GHz: 1733Mbps), ensuring ultra-smooth 4K streaming, lag-free gaming, and fast browsing across multiple devices. Powered by a 1GHz dual-core CPU with a 500MHz co-processor, the AC23 offers exceptional processing speed, enhanced stability, and optimized performance. Equipped with 7×6dBi external antennas and 4×4 MU-MIMO technology on the 5GHz band, this router provides superior coverage, stronger wall penetration, and stable multi-device connectivity for large households or multi-floor buildings.

Product Features

Ultra-Fast Dual-Band AC2100 Wi-Fi

Delivers combined Wi-Fi speeds up to 2033Mbps — 1733Mbps on 5GHz for high-bandwidth applications and 300Mbps on 2.4GHz for everyday tasks. Ideal for streaming, gaming, and high-speed downloads.

Dual-Core CPU for Powerful Performance

The 28nm 1GHz processor paired with a 500MHz co-processor ensures smooth multitasking, efficient data handling, and stable connections for all devices, even under heavy load.

7×6dBi High-Gain Antennas for Maximum Coverage

Equipped with seven external high-gain antennas, the AC23 delivers outstanding signal coverage and superior wall penetration, eliminating dead zones and ensuring consistent connectivity throughout your home.

4×4 MU-MIMO and Beamforming+ Technology

The 4×4 MU-MIMO on the 5GHz band allows multiple devices to communicate simultaneously without interference, while Beamforming+ focuses Wi-Fi signals toward connected devices for stronger and more efficient connections.

Full Gigabit Ports for High-Speed Wired Connections

Features one Gigabit WAN port and three Gigabit LAN ports supporting up to 1000Mbps, providing ultra-fast wired performance for gaming consoles, PCs, and smart TVs.

Smart Network Optimization

Integrated Smart Traffic Prioritization ensures bandwidth efficiency, automatically giving priority to streaming and gaming devices for a smooth, uninterrupted online experience.

Advanced Security and Parental Control

Includes WPA/WPA2 encryption, firewall protection, and parental control options such as blacklists and whitelists to protect your network and manage access effectively.

Flexible Operating Modes

Supports Router Mode, Universal Repeater Mode, and WISP Mode to adapt to a variety of networking needs and scenarios.

Energy-Saving and Smart Wi-Fi Scheduling

The Smart Wi-Fi Schedule and Power Saving Mode help reduce energy usage while Smart LED Control ensures a comfortable, distraction-free environment.

VPN, DDNS, and Remote Management Support

Supports PPTP, L2TP, and IPsec VPN for secure connections and Dynamic DNS (DDNS) services for remote access. Manage your network anytime using the Tenda App or Tenda Cloud.

Product Specifications

• Wireless Standards: IEEE 802.11ac Wave 2.0 / a / n (5GHz), IEEE 802.11b / g / n (2.4GHz)
• Frequency Bands: Simultaneous 2.4GHz and 5GHz
• Data Rates:
  • 2.4GHz: Up to 300Mbps
  • 5GHz: Up to 1733Mbps
• Total Speed: 2033Mbps combined
• Processor: Dual-core 1GHz CPU with 500MHz co-processor
• Antennas: 7 × 6dBi external high-gain antennas
• Ports:
  • 1 × 10/100/1000Mbps WAN port
  • 3 × 10/100/1000Mbps LAN ports
• Buttons: WPS/Reset
• Transmit Power:
  • 2.4GHz: <20dBm
  • 5GHz: <23dBm
• Wireless Security: WPA-PSK/WPA2-PSK, WPA/WPA2, WPS encryption
• Operating Modes: Router, Universal Repeater, WISP
• Management: Local web interface, Remote management via Tenda App
• DHCP: Server, Client, Reservation
• Firewall Protection: UDP, TCP, and ICMP flood protection; WAN ping disable
• VPN Support: PPTP, L2TP, IPsec pass-through; PPTP/L2TP client and server
• DDNS Support: DynDNS, Oray.com, 88ip
• Smart Features:
  • Smart Wi-Fi Scheduling
  • Smart Power Saving
  • Smart LED On/Off Control
  • Traffic Prioritization
  • Alexa Compatibility
• Other Functions:
  • Bandwidth Control
  • IPTV
  • MAC Clone
  • Static Routing
  • Backup & Restore Configurations
  • Online and Browser Firmware Upgrades
  • IPv6 Support
• Power Supply: Input: AC 100–240V~50/60Hz 0.6A; Output: DC 12V 1.5A
• Dimensions: 238.9 × 144.3 × 40.3 mm
• Operating Temperature: 0°C – 40°C
• Storage Temperature: -40°C – 70°C
• Operating Humidity: 10% – 90% RH (non-condensing)
• Storage Humidity: 5% – 90% RH (non-condensing)
• Certifications: CE, FCC, RoHS

Package Contents

• 1 × Tenda AC23 Dual-Band Gigabit Router
• 1 × Power Adapter
• 1 × Ethernet Cable
• 1 × Installation Guide
