TP-Link CPE220 2.4GHz 300Mbps 12dBi Outdoor CPE

The TP-Link CPE220 is a professional-grade 2.4GHz outdoor wireless device, engineered to deliver long-range point-to-point and point-to-multipoint networking. With a built-in 12dBi directional antenna, up to 300Mbps throughput, and robust weatherproof housing, it is optimized for wireless internet distribution, outdoor Wi-Fi coverage, and surveillance applications. Its centralized management platform, Pharos Control, makes it scalable for enterprise and ISP deployments, while offering simplicity and performance for home and small business users.

Product Features

Advanced TDMA Technology

The CPE220 uses TP-Link’s proprietary Pharos MAXtream TDMA technology to improve network performance by reducing latency and increasing throughput and stability, especially in point-to-multipoint setups.

Multiple Operating Modes

Supports various operation modes including Access Point, Client, Repeater, Bridge, AP Router, and WISP Client Router, providing flexibility for different deployment scenarios.

Centralized Management

Managed via Pharos Control, a centralized network management software that allows for discovery, configuration, monitoring, and firmware upgrades across multiple devices.

High-Gain Directional Antenna

Equipped with a 12dBi dual-polarized directional antenna offering 60° horizontal and 30° vertical beamwidth for long-range wireless communication.

PoE Deployment and Remote Reset

Includes a Passive PoE adapter that supports up to 60 meters (200 feet) of Ethernet cable, enabling flexible installation and remote resetting of the device.

Industrial-Grade Protection

Features 15kV ESD and 6kV lightning protection with a rugged IPX5 weatherproof enclosure for reliable outdoor performance under extreme conditions.

Product Specifications

• Processor: Qualcomm Atheros 560 MHz CPU (MIPS 24Kc)
• Memory: 64 MB DDR2 RAM, 8 MB Flash
• Ethernet Ports:
  • 1 × 10/100 Mbps Shielded Ethernet Port (LAN0, Passive PoE in)
  • 1 × 10/100 Mbps Shielded Ethernet Port (LAN1)
• Grounding Terminal: Yes
• Reset Button: Yes

Powering

• Power Supply: 24V Passive PoE
• Input Voltage Range: 16–27V DC
• Maximum Power Consumption: 10.8 W

Antenna

• Type: Built-in 2×2 Dual-Polarized Directional Antenna
• Gain: 12 dBi
• Beamwidth: 60° (H-Plane), 30° (E-Plane)

Wireless

• Frequency Band: 2.4–2.483 GHz (regional restrictions may apply)
• Standards: IEEE 802.11b/g/n
• Data Rates:
  • Up to 300 Mbps (40 MHz)
  • Up to 144.4 Mbps (20 MHz)
  • Up to 72.2 Mbps (10 MHz)
  • Up to 36.1 Mbps (5 MHz)
• Transmission Power: Up to 30 dBm (1000 mW), adjustable
• Wireless Modes: AP, Client, Repeater, Bridge, AP Router, AP Client Router (WISP)

Wireless Features

• Pharos MAXtream TDMA
• Dynamic Frequency Selection (DFS)
• Transmission Power Control
• Multi-SSID with VLAN tagging
• Wireless MAC Filtering
• WPA/WPA2 and WEP encryption
• Short GI, RTS Threshold, Fragmentation Threshold, Beacon Interval, DTIM

Management and Monitoring

• Management Software: Pharos Control
• Web Management: HTTP/HTTPS
• Other Tools: SNMP v2c, Ping Watchdog, DDNS, SSH
• Monitoring Tools: Spectrum Analyzer, Speed Test, Signal Quality, System Log

Enclosure and Environmental Ratings

• Material: ASA-stabilized outdoor plastic
• Waterproof Rating: IPX5
• Lightning/ESD Protection: 6 kV lightning, 15 kV ESD
• Operating Temperature: -40°C to +70°C
• Storage Temperature: -40°C to +70°C
• Operating Humidity: 10%–90% non-condensing
• Storage Humidity: 5%–95% non-condensing

PoE Adapter

• Dimensions: 85.8 × 43.9 × 31.9 mm
• Input: 100–240V AC, 50/60 Hz
• Output: 24V DC, 0.5 A Max
• Remote Reset Button: Yes
• Efficiency: Over 80%
• Certifications: CE, FCC, UL, IC, GS, SAA, KC-Mark

Certifications

• CE, FCC, RoHS, IPX5

Package Contents

• TP-Link CPE220 Outdoor Unit
• 24V 0.5A Passive PoE Adapter
• Power Cord
• Pole Mounting Straps
• Installation Guide

System Requirements

• Microsoft Windows 98SE or later
• macOS, NetWare, UNIX, or Linux
• Recommended Browsers: Google Chrome, Firefox, Safari (Internet Explorer not recommended)

Applications

Point-to-Point Wireless Bridging
Ideal for linking remote buildings or surveillance cameras with strong, stable connections.

Point-to-Multipoint Deployments
Supports multiple client devices in rural broadband and WISP installations with Pharos MAXtream for reduced interference.

Outdoor Wi-Fi Coverage
A reliable solution for extending wireless coverage in outdoor campuses, parks, or construction sites.
