TP-Link TL-WPA7517 KIT AV1000 Gigabit Powerline AC Wi-Fi Kit (AC1200)

The TP-Link TL-WPA7517 KIT AV1000 Powerline AC Wi-Fi Kit transforms your home’s existing electrical wiring into a powerful, high-speed network—bringing wired and wireless connectivity to areas where your router’s Wi-Fi can’t reach. This dual-device kit includes the TL-WPA7517 Wi-Fi extender and TL-PA7017 powerline adapter, providing seamless internet access through walls and floors without the need for additional wiring.

Equipped with HomePlug AV2 technology and dual-band AC1200 Wi-Fi (300 Mbps on 2.4 GHz and 867 Mbps on 5 GHz), the TL-WPA7517 KIT supports bandwidth-intensive activities such as HD video streaming, online gaming, and large file transfers. With easy one-touch Wi-Fi cloning, gigabit Ethernet support, and compatibility with TP-Link’s OneMesh™ ecosystem, this kit is the ideal solution for expanding reliable internet throughout your home.

Product Features

High-Speed Powerline Transmission

Delivers data speeds up to 1000 Mbps over your home’s electrical wiring, extending your network up to 300 meters without signal degradation.

Dual-Band AC1200 Wi-Fi

Provides stable and fast wireless coverage with 300 Mbps on 2.4 GHz and 867 Mbps on 5 GHz—ideal for reducing interference and improving overall network performance.

Seamless Wi-Fi Configuration

The Wi-Fi Clone button allows for automatic synchronization with your router’s SSID and password, simplifying setup and maintaining consistent connectivity across devices.

Gigabit Ethernet Port

Includes one gigabit Ethernet port per adapter for high-speed wired connections, perfect for devices like smart TVs, game consoles, PCs, or network switches.

Easy Management via tpPLC App

Download the tpPLC App on Android or iOS, or use the PC utility to monitor, control, and manage your powerline network and settings effortlessly.

OneMesh™ Support

Integrates seamlessly with other TP-Link OneMesh™ products to create a unified, flexible whole-home Wi-Fi network without the need to replace your current devices.

Product Specifications

• Plug Type: EU
• Networking Standards: HomePlug AV2, HomePlug AV, IEEE 1901, 802.3, 802.3u, 802.3ab, 802.11b/g/n (2.4GHz), 802.11a/n/ac (5GHz)
• Powerline Transmission Speed: Up to 1000 Mbps
• Wireless Speed:
  • 2.4 GHz: 300 Mbps
  • 5 GHz: 867 Mbps
• Ethernet Port:
  • TL-WPA7517: 1 × Gigabit Ethernet
  • TL-PA7017: 1 × Gigabit Ethernet
• Encryption:
  • Powerline: 128-bit AES
  • Wireless: WPA-PSK / WPA2-PSK / WEP
• Management Tools: tpPLC App (Android/iOS), tpPLC Utility (Windows)
• Buttons: Pair, Reset, Wi-Fi Clone, LED On/Off
• LED Indicators: Power, Powerline, Ethernet, Wi-Fi (2.4 GHz), Wi-Fi (5 GHz)
• Max Range: Up to 300 meters over existing electrical wiring
• Power Consumption:
  • TL-WPA7517: Max 11W, Typical 6.5W
  • TL-PA7017: Max 2.9W, Typical 2.6W
• Operating Temperature: 0°C to 40°C (32°F to 104°F)
• Operating Humidity: 10% to 90% non-condensing
• Dimensions:
  • TL-WPA7517: 69.5 × 35 × 124.1 mm
  • TL-PA7017: 52 × 28.5 × 65 mm
• Compatibility: Works with all HomePlug AV and AV2 powerline adapters
• Certifications: CE, RoHS
• System Requirements: Windows 10/8.1/8/7/Vista/XP, Mac OS, Linux
• Package Contents:
  • 1 × TL-WPA7517
  • 1 × TL-PA7017
  • 2 × Ethernet Cables
  • Quick Installation Guide
