TP-Link VIGI 2MP IR Dome Network Camera (VIGI C220I)

The TP-Link VIGI 2MP IR Dome Network Camera (VIGI C220I) delivers professional-grade Full HD surveillance with advanced human and vehicle classification, smart detection features, and rugged IK10 vandal-proof housing. Designed for reliable indoor and outdoor deployment, this IP67 waterproof dome camera supports H.265+ compression for efficient bandwidth usage and simplified PoE installation. Ideal for retail stores, offices, warehouses, and commercial buildings, the VIGI C220I ensures clear 1080p video, intelligent event monitoring, and secure remote management.

Product Features

2MP Full HD Video Surveillance

Capture detailed 1920 × 1080 resolution footage with a 1/3 inch Progressive Scan CMOS sensor, delivering sharp and reliable Full HD video for professional security monitoring.

Human and Vehicle Classification

Advanced analytics distinguish humans and vehicles from other moving objects, reducing false alarms and improving event accuracy for smarter notifications.

Smart Detection and Event Alerts

Receive real-time alerts for line-crossing detection, area intrusion, region entry or exit, object removal or abandonment, video tampering, and illegal login attempts.

IK10 Vandal-Proof and IP67 Waterproof Design

Built with durable housing, the camera withstands impact, vandalism, rain, and dust, making it suitable for demanding indoor and outdoor environments.

H.265+ Video Compression

Optimized H.265+ technology reduces bandwidth consumption and storage requirements while maintaining high image quality.

Smart Video Enhancement Technologies

Professional image processing features including Smart IR, DWDR, 3D DNR, BLC, and HLC enhance clarity in challenging lighting conditions.

Flexible 2.8 mm or 4 mm Fixed Lens Options

Choose between a wide-angle 2.8 mm lens for broad coverage or a 4 mm lens for longer-distance monitoring to suit various surveillance scenarios.

Simplified PoE Deployment

Power and transmit data through a single RJ45 Ethernet cable with IEEE 802.3af/at PoE support, eliminating the need for a separate power adapter.

Flexible Management and Remote Access

Manage your surveillance system through the VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS, or PC Client for complete security control.

Product Specifications

• Image Sensor: 1/3 inch Progressive Scan CMOS
• Maximum Resolution: 1920 × 1080 (Full HD)
• Shutter Speed: 1/3 to 1/10000 s
• Minimum Illumination: 0.01 Lux (Color), 0 Lux with IR
• Day/Night Mechanism: IR Cut Filter
• Lens Type: Fixed Focal Lens (2.8 mm or 4 mm)
• Aperture: F2.2 (2.8 mm), F2.0 (4 mm)
• Lens Mount: M12
• Field of View (2.8 mm): 88.2° horizontal, 48.7° vertical, 106.5° diagonal
• Field of View (4 mm): 74.6° horizontal, 41.3° vertical, 88.1° diagonal
• DORI Distance (2.8 mm): Detect 45 m, Observe 19 m, Recognize 9 m, Identify 5 m
• DORI Distance (4 mm): Detect 60 m, Observe 25 m, Recognize 12 m, Identify 6 m
• IR LEDs: 2 LEDs, 30 m range, 850 nm wavelength
• Pan Adjustment: 0° to 355°
• Tilt Adjustment: 0° to 75°
• Video Compression: H.265+/H.265/H.264+/H.264 (Main Stream), H.265/H.264 (Sub-Stream)
• Bit Rate Control: CBR, VBR
• Video Bit Rate: Main Stream 256 Kbps to 4 Mbps, Sub-Stream 64 Kbps to 512 Kbps
• Wide Dynamic Range: DWDR
• Signal-to-Noise Ratio: ≥ 52 dB
• Privacy Mask: Up to 4 masks
• ROI: 1 region supported
• Network Interface: 1 × RJ45 10/100M self-adaptive Ethernet port
• Protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP, SSL/TLS, FTP/SFTP, RTP, IPv4, ARP, SMTP, SNMP
• ONVIF: Profile S/T supported
• Simultaneous Live View: 3 main streams and 3 sub-streams
• Cloud Support: Yes
• Security: Password protection, HTTPS encryption, IP address filtering, Digest authentication
• Power Supply: PoE 802.3af/at, Class 0, Max. 5.5 W
• Protection Rating: IP67, IK10
• Material: Plastic
• Operating Temperature: -30 °C to 60 °C
• Storage Temperature: -40 °C to 60 °C
• Operating Humidity: ≤ 95% non-condensing
• Storage Humidity: ≤ 95% non-condensing
• Dimensions (L × W × H): 115 × 86 × 115 mm (4.5 × 3.4 × 4.5 in)
• Net Weight: 0.26 kg
• Gross Weight: 0.43 kg
• Certifications: CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC
• Package Content: VIGI Network Camera, Quick Start Guide, Waterproof Cable Attachments, Mounting Accessories
