TP-Link VIGI C540 4MP Outdoor Full-Color Pan Tilt Network Camera (VIGI C540)

The TP-Link VIGI C540 is a 4MP outdoor pan-tilt network camera designed for full-color, round-the-clock surveillance. With intelligent human and vehicle classification, automatic tracking, and powerful Pan Tilt patrol features, this camera delivers precise monitoring and enhanced security for homes, businesses, and commercial properties. Active defense with audible and visual alarms, two-way audio, and smart detection ensures instant response to abnormal events. Its H.265+ compression, IP66 weatherproof design, and flexible management options make it a reliable solution for comprehensive and efficient outdoor security.

Product Features

4MP Super-High Definition

Provides crystal-clear 2560 × 1440 video to capture detailed images for reliable monitoring of all critical areas.

24-Hour Full-Color Monitoring

Large-aperture lens, high-sensitivity sensor, and supplemental white lights ensure vibrant full-color images even in complete darkness.

Powerful Pan Tilt

Customizable patrol routes and automatic tracking allow intelligent monitoring of key areas, improving security coverage.

Human & Vehicle Classification

Accurately differentiates humans and vehicles from other objects, reducing false alerts and providing more meaningful notifications.

Smart Detection

Detects boundary crossings, area entry, obstruction, and object removal or abandonment, sending immediate notifications to users.

Automatic Tracking

Follows moving persons or vehicles intelligently, ensuring continuous monitoring of objects of interest.

Active Defense

Instantly warns intruders with sound and light when abnormal activity is detected, enhancing deterrence.

Two-Way Audio

Supports real-time communication through the built-in microphone and speaker for monitoring and interaction.

Smart Video Enhancement

Includes Smart IR, DWDR, 3D DNR, and HLC technologies to improve image quality in challenging lighting conditions.

H.265+ Video Compression

Reduces file sizes without compromising video quality, saving storage space and minimizing network bandwidth.

IP66 Weatherproof

Durable construction ensures stable outdoor performance even under harsh weather conditions.

Flexible Management & Storage

Supports Web UI, NVR UI, VIGI App, and VIGI Security Manager with onboard microSD storage up to 512 GB.

Product Specifications

• Image Sensor: 1/3” Progressive Scan CMOS
• Maximum Resolution: 2560 × 1440 (4MP)
• Shutter Speed: 1/3 to 1/10000 s
• Minimum Illumination: 0 Lux (with IR/White Light)
• Lens: Fixed Focal Lens, 4 mm, F1.6, M12 Mount
• Field of View (4 mm): 79° H / 43° V / 93° D
• DORI Distance: Detect 80 m, Observe 33 m, Recognize 16 m, Identify 8 m
• PTZ Pan/Tilt Range: Pan 0°–350°, Tilt 0°–120°
• PTZ Pan/Tilt Speed: Configurable Pan 1°–55°/s, Tilt 1°–40°/s
• Presets: 300
• Patrol Scans: 8 patrols, up to 8 presets per patrol
• IR Illuminators: 2 × IR LED, 30 m range
• White LEDs: 2 × White LED, 30 m range
• Video Compression: H.265+/H.265/H.264+/H.264
• Maximum Video Bit Rate: Main Stream 256 Kbps – 4 Mbps, Sub Stream 64 Kbps – 512 Kbps
• WDR: DWDR
• Image Enhancement: BLC / 3D DNR / HLC / SmartIR
• Two-Way Audio: Built-in Microphone and Speaker, 8 kHz, 64 Kbps (G.711 alaw)
• Network Interface: 1 × RJ45 10/100M Ethernet
• ONVIF: Yes
• Smart Events: Human & Vehicle Classification, Area Intrusion, Line-Crossing, People/Vehicle Detection, Region Enter/Exit, Object Abandoned/Removal
• Basic Events: Motion Detection, Video Tampering, Illegal Login
• Alarm Linkage: Memory Card Recording, Message Push, Audible Warning, White Light Flashing
• Storage: Onboard microSD card up to 512 GB
• Power Supply: 12V DC ±5%, Max 14 W; PoE 802.3af/at, Class 4
• Operating Temperature: -30–60 °C
• Operating Humidity: ≤95% Non-condensing
• Dimensions: 120 × 172 × 198 mm
• Weight: 195 g
• Protection Rating: IP66
• Certifications: CE, RCM, BSMI, VCCI, RoHS, NTRA, KC
