D-Link DMC-530SC Twisted-Pair to Single-Mode Fiber Smart Media Converter (30km)

Original price was: KSh23,000.Current price is: KSh17,000. Exc. VAT

  • Supports Single-mode Fiber Cable Distance Up To 30 km
  • 1x 10/100BASE-TX RJ-45 port & 1 x 10/100BASE-FX SC port
  • 200 Mbps (full-duplex)
  • Auto-MDI/MDIX
  • Can be used as a stand-alone device or installed in a chassis

IMPORTANT NOTICE !!!

D-Link DMC-530SC Twisted-Pair to Single-Mode Fiber Smart Media Converter (30km)

The DMC-530SC Media Converter converts 10/100Mbps 10BASE-T/100BASETX Fast Ethernet twisted-pair signals to 100BASE-FX Fast Ethernet single-mode fiber signals. The DMC-530SC has a maximum fiber cable distance is 30 km and it has 1x RJ-45 twisted-pair port and 1x fiber port (SC connector) are provided.

Product Features

Dedicated Storage Solution

The DMC Series product lineup includes a wide range of independent media converters as well as the DMC-1000 Media Converter Chassis, capable of housing up to 16 media converters. You can start with a single media converter, equipped with its own housing and AC power supply. As network requirements grow, you can mount the DMC-1000 in your equipment rack and conveniently install all your media converters into the chassis. The housing of each media converter can be easily removed, allowing it to be installed into the chassis. The installed converter module is then powered by the chassis’ power supply.

Flexible Media Conversion

Media converters convert signals that are transmitted from one type of media to another so that they can be transmitted over a different type of media. This series of media converters converts 10/100/1000 Mbps copper Ethernet to a 100/1000 Mbps fiber optic connection. This allows you to expand your network by connecting longer distance, high-speed fiber optic cables between devices that are otherwise connected with short distance Ethernet cables, such as Cat. 5 twisted-pair cables.

Remote Management

The DMC-1000 chassis can also be equipped with the DMC-1002 Management Module. This module allows administrators to remotely manage and monitor the real-time status of all media converters and power supplies in the chassis, and sends out alarms to alert you of any abnormal situations. The management module follows industry standards, including SNMP and HTTP, allowing you to monitor and manage the mounted media converters and power supplies from a third-party SNMP Network Management Station (NMS) or via a web browser.

Product Specifications

Interface

Number of Ports

  • 1 x 10/100BASE-TX RJ-45 port
  • 1 x 10/100BASE-FX SC port

Standards

  • IEEE 802.3 for 10BASE-T/F
  • EEE 802.3u for 100BASE-TX/FX

Data Transfer Rate

  • Ethernet: 10 Mbps/20 Mbps (halfduplex/full-duplex)
  • Fast Ethernet: 100 Mbps/200 Mbps (half-duplex/full-duplex)

Duplex Mode

  • Half-duplex/full-duplex

Media Types

  • 10BASE-T: 2-pair Cat. 3/4/5/5e, Unshielded Twisted Pair (UTP) (up to 100 m)
  • 10/100BASE-TX: 2-pair Cat. 5/5e, Unshielded Twisted Pair (UTP) (up to 100 m)
  • 100BASE-FX: Multi-mode fiber optic cable with SC connector (up to 2 km)

Media Exchange Interface

  • Auto-MDI/MDIX

Functionality

Transmission Mode

  • Store-and-forward

Forwarding Rate

  • Full wire-speed forwarding rate

Management

  • Through the DMC-1000 chassis with the DMC-1002 management module installed

Management Functions

  • Fiber port duplex mode

Physical

Diagnostic LEDs

  • Power
  • Speed (for twisted pair ports)
  • Full-duplex/Collision (for twisted pair and fiber ports)
  • LINK/ACT (for twisted pair ports)

AC Input

  • 5 V/1 A external power adapter

Temperature

  • Operating: 0 °C to 40 °C (32 °F to 104 °F)
  • Storage: -25 °C to 70 °C (13 ºF to 158 °F)

Humidity

  • 10% to 90% RH, non-condensing

Dimensions

  • 120 x 88 x 25 mm (4.72 x 3.46 x 0.98 in)

Weight

  • 292 g (0.64 lbs)

Fiber Wavelength

  • 1310 nm

Supported Fiber Cable Length

  • Up to 30 km

Emission Certifications (EMI)

  • FCC Class A
  • VCCI Class A
  • CE Class A
