Omada 28-Port Gigabit Easy Managed Switch with 24-Port PoE+ (ES228GMP)
The TP-Link Omada ES228GMP is a high-capacity, rack-mountable switch designed for enterprise networks and large-scale surveillance deployments. Featuring 24 PoE+ ports with a total 384W power budget, plus two additional Gigabit RJ45 ports and two Gigabit SFP slots, it delivers both data and power over a single network cable. Fully integrated with the Omada SDN platform, it provides centralized cloud management, VLAN segmentation, advanced QoS, and Layer 2 features, making it ideal for high-density IP camera networks, access points, and other critical network devices.
Product Features
24 PoE+ Ports with 384W Power Budget
Supports 24× 802.3af/at-compliant PoE+ RJ45 ports, delivering up to 30W per port and a total power budget of 384W. Ideal for powering large-scale IP surveillance networks and multiple wireless access points simultaneously.
Additional Connectivity Options
Includes two standard Gigabit RJ45 ports and two Gigabit SFP slots for fiber uplinks or network expansion, providing flexible deployment options in enterprise networks.
Extended 250m PoE Transmission
Supports PoE transmission distances up to 250 meters, allowing long-distance deployments without additional power infrastructure.
Fast PoE and PoE Auto Recovery
Fast PoE enables rapid power-on for connected devices during switch boot. PoE Auto Recovery automatically detects and reboots unresponsive powered devices to ensure network reliability.
Centralized Omada Cloud Management
Integrates seamlessly with Omada controllers for centralized cloud management via web interface or Omada app. Zero-Touch Provisioning and unified configuration simplify multi-site network deployment and monitoring.
Advanced QoS and Traffic Control
Supports port-based, 802.1p, and DSCP QoS with eight priority queues and Weighted Round Robin scheduling. Bandwidth control and storm control help maintain optimal performance for latency-sensitive applications like IP video streaming and VoIP.
VLAN and Layer 2 Networking Features
Supports 802.1Q Tag VLAN, Port-Based VLAN, and MTU VLAN with up to 32 VLAN groups and 4K VIDs. Additional Layer 2 features include static link aggregation, loop prevention, flow control (802.3x), port mirroring, LLDP, and IGMP Snooping for efficient multicast traffic management.
Rack-Mountable and Durable Metal Design
Durable metal chassis with fan-assisted cooling ensures high reliability in enterprise environments. Rack-mountable design simplifies integration into server racks and network cabinets. Surge protection up to ±6kV enhances device safety.
Plug-and-Play with Web-Based Management
Supports plug-and-play connectivity for instant setup. Additional configuration is available via a web-based GUI with features like cable diagnostics, DHCP client, batch configuration, and firmware upgrades.
Product Specifications
- Ports: 24× 10/100/1000 Mbps PoE+ RJ45, 2× 10/100/1000 Mbps RJ45, 2× Gigabit SFP
- PoE Budget: 384W Total, Up to 30W per Port
- Switching Capacity: 56 Gbps
- Packet Forwarding Rate: 41.67 Mpps
- MAC Address Table: 8K
- Packet Buffer Memory: 4 Mbit
- Jumbo Frame: 15 KB
- VLAN Support: 802.1Q Tag VLAN, Port-Based VLAN, MTU VLAN (Max 32 VLAN Groups, 4K VID)
- QoS: Port-Based/802.1p/DSCP QoS, 8 Priority Queues
- Multicast: IGMP v1/v2/v3 Snooping, Fast Leave
- Transmission Method: Store-and-Forward
- Surge Protection: ±6kV
- Power Supply: 100–240V AC, 50/60Hz
- Cooling: 2 Fans
- Installation: Rack-Mountable
- Enclosure: Metal
- Dimensions: 440 × 330 × 44 mm (17.3 × 13.0 × 1.7 in)
- Operating Temperature: -5°C to 45°C
- Storage Temperature: -40°C to 70°C
- Operating Humidity: 10% to 90% Non-Condensing
- Storage Humidity: 5% to 90% Non-Condensing
- Certifications: FCC, CE, RoHS
