TP-Link Omada ES206GP 6-Port Gigabit Easy Managed Switch with 4-Port PoE+

TP-Link Omada ES206GP 6-Port Gigabit Easy Managed Switch with 4-Port PoE+ is a compact Gigabit managed switch designed for small businesses, retail environments, IP surveillance systems, and wireless network deployments. Featuring six Gigabit Ethernet ports, including four IEEE 802.3af/at-compliant PoE+ ports with a 65W total PoE budget, it delivers both power and high-speed data through a single Ethernet cable, reducing installation costs while simplifying network expansion.

Fully integrated with the TP-Link Omada SDN platform, the ES206GP provides centralized cloud management, intelligent Layer 2 switching, VLAN segmentation, QoS optimization, and advanced monitoring capabilities. With Fast PoE, PoE Auto Recovery, long-distance PoE support, and a durable fanless metal enclosure, it offers dependable networking for modern business environments.

Browse our complete range of Network Switches in Kenya to find managed, unmanaged, PoE, Gigabit, Multi-Gig, and enterprise switching solutions for businesses, campuses, CCTV surveillance, data centres, and industrial networks. You can also explore our full selection of TP-Link Network Switches or browse the complete TP-Link Online Store in Kenya for enterprise networking equipment, wireless access points, routers, network accessories, and other genuine TP-Link networking solutions at competitive prices.

Features of the TP-Link Omada ES206GP 6-Port Gigabit Easy Managed Switch with 4-Port PoE+ in Kenya

6 Gigabit Ports with 4 PoE+ Ports

Six Gigabit Ethernet ports provide reliable high-speed connectivity, while four IEEE 802.3af/at PoE+ ports deliver up to 30W per port to power IP cameras, wireless access points, VoIP phones, and other compatible devices.

65W Total PoE Budget

The integrated 65W PoE budget allows multiple powered devices to operate simultaneously, making the switch ideal for small surveillance systems and wireless deployments.

Extended PoE Transmission

Supports PoE transmission distances of up to 250 metres, allowing flexible installation of cameras and other powered devices without requiring additional power infrastructure.

Fast PoE and PoE Auto Recovery

Fast PoE speeds up powered device startup during switch boot, while PoE Auto Recovery automatically detects and restarts unresponsive devices to maximize network availability.

Centralized Omada SDN Management

Works seamlessly with Omada Hardware Controllers, Software Controllers, and Cloud-Based Controllers for centralized monitoring, Zero-Touch Provisioning, remote configuration, firmware upgrades, and network management.

Advanced Layer 2 Networking

Supports Static Link Aggregation, IEEE 802.3x Flow Control, LLDP, Port Mirroring, Loop Prevention, and IGMP Snooping for stable, efficient, and secure network operation.

VLAN and Intelligent QoS

Supports IEEE 802.1Q VLAN, MTU VLAN, Port-Based VLAN, bandwidth control, storm control, and 802.1p/DSCP QoS with eight priority queues to optimize business-critical traffic.

Silent Fanless Design

The fanless metal enclosure ensures completely silent operation while improving long-term reliability and minimizing maintenance requirements.

Flexible Installation

The compact metal chassis supports both desktop placement and wall mounting, making it suitable for offices, retail stores, communication cabinets, and surveillance installations.

Simple Web-Based Management

Supports plug-and-play deployment with advanced configuration through a user-friendly web interface featuring cable diagnostics, DHCP client support, firmware upgrades, and batch configuration.

Specifications of the TP-Link Omada ES206GP 6-Port Gigabit Easy Managed Switch with 4-Port PoE+ in Kenya

• Model: ES206GP
• Ports: 6 × 10/100/1000Mbps RJ45 Ports
• PoE Ports: 4 × IEEE 802.3af/at PoE+ Ports
• Maximum PoE Output per Port: 30W
• Total PoE Budget: 65W
• Switching Capacity: 12Gbps
• Packet Forwarding Rate: 7.4Mpps
• MAC Address Table: 8K Entries
• Packet Buffer Memory: 4Mbit
• Jumbo Frame Support: 15KB
• Transmission Method: Store-and-Forward
• VLAN Support: IEEE 802.1Q Tag VLAN, Port-Based VLAN, MTU VLAN (Up to 32 VLAN Groups, 4K VID)
• QoS: Port-Based, IEEE 802.1p, DSCP QoS, 8 Priority Queues
• Multicast: IGMP v1/v2/v3 Snooping with Fast Leave
• Layer 2 Features: Static Link Aggregation, Loop Prevention, IEEE 802.3x Flow Control, Port Mirroring, LLDP
• PoE Features: Fast PoE, PoE Auto Recovery, Long-Distance PoE
• Surge Protection: ±6kV
• Power Supply: 53.5V DC / 1.31A Adapter
• Installation: Desktop or Wall Mount
• Enclosure: Metal
• Cooling Method: Fanless
• Dimensions: 158 × 101 × 25mm
• Operating Temperature: -5°C to 40°C
• Storage Temperature: -40°C to 70°C
• Operating Humidity: 10%–90% RH (Non-condensing)
• Storage Humidity: 5%–90% RH (Non-condensing)
• Certifications: FCC, CE, RoHS

Applications of the TP-Link Omada ES206GP 6-Port Gigabit Easy Managed Switch with 4-Port PoE+

• Small business LAN deployments.
• IP CCTV surveillance systems.
• Wireless access point installations.
• VoIP phone deployments.
• Retail stores and branch offices.
• Schools and healthcare facilities.
• Hotel and hospitality networking.
• Small enterprise edge networks.

Buy the TP-Link Omada ES206GP 6-Port Gigabit Easy Managed Switch with 4-Port PoE+ in Kenya

The TP-Link Omada ES206GP 6-Port Gigabit Easy Managed Switch with 4-Port PoE+ is available in Kenya from Rapidtech Networks Limited, your trusted supplier of genuine TP-Link networking equipment. We supply authentic Omada managed switches backed by manufacturer warranty, competitive pricing, and expert technical support for business networking, surveillance systems, wireless infrastructure, and enterprise deployments.

We offer fast countrywide delivery to Nairobi, Mombasa, Kisumu, Nakuru, Eldoret, Thika, Kiambu, Machakos, Nyeri, Meru, Embu, Kakamega, Kisii, Kitale, Naivasha, Kericho, Bungoma, Garissa, Malindi and other towns throughout Kenya.

Our engineers also provide professional network design, switch configuration, structured cabling, PoE deployment, Omada SDN implementation, installation, commissioning, and reliable after-sales technical support.
