Baofeng UV-5R Dual Radio 5-8KM (2 Pieces)

The Baofeng UV-5R Dual Radio 5-8KM (2 Pieces) is a reliable dual-band walkie talkie solution designed for clear and efficient communication in outdoor adventures, security operations, construction sites, events, and recreational activities. Supporting both VHF and UHF frequencies, these handheld radios provide dependable communication coverage of up to 5–8 km depending on terrain and environmental conditions. With 128 programmable channels, dual display functionality, rechargeable batteries, VOX hands-free operation, and built-in safety features, the BaoFeng UV-5R radios deliver practical and professional communication performance for everyday use.

Product Features

Dual Band VHF and UHF Operation

The Baofeng UV-5R supports VHF 136–174 MHz and UHF 400–520 MHz frequencies for flexible communication across multiple environments and communication systems.

Long Range Communication

Designed for reliable communication with an approximate range of 5–8 km depending on terrain, obstacles, and environmental conditions.

128 Programmable Channels

The radios support 128 programmable channels with multiple channel spacing options for organized communication and enhanced operational flexibility.

Dual Display and Dual Standby

The dual-band display allows simultaneous monitoring of VHF and UHF frequencies for improved communication management and convenience.

Adjustable RF Power Output

Users can switch between high 5W and low 1W transmission power modes to optimize communication range and battery efficiency.

Rechargeable Long-Life Battery

Each radio includes a 1800mAh Li-ion rechargeable battery designed to provide approximately 8 hours of operation under normal usage conditions.

VOX Hands-Free Function

The built-in VOX feature enables automatic voice-activated transmission for convenient hands-free communication during work or outdoor activities.

Integrated FM Radio and Flashlight

The radios include a built-in FM radio receiver and LED flashlight for added convenience during travel, outdoor use, and emergencies.

Emergency and Safety Features

Equipped with emergency alert functionality, battery saver mode, keypad lock, and time-out timer to improve safety and operational efficiency.

Clear Audio Performance

The integrated 1W speaker provides loud and clear audio output for dependable communication in different environments.

Product Specifications

• Product Name: Baofeng UV-5R Dual Radio
• Quantity: 2 Pieces
• Frequency Range VHF: 136–174 MHz
• Frequency Range UHF: 400–520 MHz
• Channel Capacity: 128 Programmable Channels
• Channel Spacing: 2.5/5/6.25/10/12.5/25 kHz
• RF Power Output: 5W High Power and 1W Low Power
• Operating Voltage: 7.4V DC
• Battery Type: 1800mAh Li-Ion Rechargeable Battery
• Battery Life: Approximately 8 Hours
• Antenna Impedance: 50 Ω
• Communication Range: Approximately 5–8 km
• Operating Temperature: –20°C to +60°C
• Receiver Sensitivity: ≤0.20 µV
• Intermodulation: ≥60 dB
• Adjacent Channel Selectivity Wideband: ≥65 dB
• Adjacent Channel Selectivity Narrowband: ≥60 dB
• Audio Power Output: 1W
• Modulation Type: FM
• Emission Class Wideband: 16kΦF3E
• Emission Class Narrowband: 11kΦF3E
• Spurious Emission: <–60 dB
• FM Radio Frequency Range: 65–108 MHz
• VOX Hands-Free Function: Yes
• Emergency Alert Function: Yes
• Battery Saver Mode: Yes
• Time-Out Timer: Yes
• Keypad Lock: Yes
• Monitor Channel Function: Yes
• Built-In LED Flashlight: Yes
• Dimensions Without Antenna: 109.5 × 59.5 × 34.5 mm
• Weight: Approximately 225 g per Unit
• Included Accessories: 2 Radios, 2 Rechargeable Batteries, 2 High-Gain Antennas, 2 Belt Clips, 2 Earpieces, 2 Desktop Charging Docks, 1 User Manual
