R & M Patch Cord CU EL Cat6A AWG26 LSZH Grey 7m (R842755)

The R & M Patch Cord CU EL Cat6A AWG26 LSZH Grey 7m (R842755) is a high-performance Category 6A unshielded patch cable designed for reliable 10 Gigabit Ethernet connectivity in modern structured cabling systems. Manufactured by Reichle & De-Massari, this patch cord supports frequencies up to 500 MHz and delivers consistent high-speed data transmission for enterprise networks, data centers, and telecommunications environments. With a low smoke zero halogen jacket, flexible AWG 26/7 stranded copper conductors, and factory-terminated RJ45 connectors, the cable ensures safety, durability, and excellent signal integrity while remaining compatible with Cat5e and Cat6 network infrastructures.

Product Features

Category 6A Performance for 10 Gigabit Ethernet

Designed to meet Category 6A Class EA standards, this patch cord supports frequencies up to 500 MHz and data transmission speeds up to 10 Gbps, ensuring reliable high-bandwidth network connectivity.

Unshielded Twisted Pair Construction

The U/UTP design with four twisted pairs provides efficient data transmission and flexible cable management, making it suitable for structured cabling systems in office networks and data centers.

LSZH Jacket for Safer Installations

The low smoke zero halogen outer sheath reduces the emission of toxic fumes and smoke in the event of a fire, making it ideal for indoor installations in commercial buildings and network facilities.

Flexible Stranded Copper Conductors

Built with AWG 26/7 stranded copper wires, the cable provides improved flexibility for routing in patch panels, racks, and network cabinets without compromising signal performance.

High-Quality RJ45 Connectors with Gold-Plated Contacts

The cable is terminated with unshielded RJ45 connectors featuring gold-plated contacts for enhanced conductivity, corrosion resistance, and reliable long-term connections.

Advanced Power over Ethernet Support

This patch cord supports IEEE 802.3af, IEEE 802.3at, and IEEE 802.3bt standards, allowing the cable to deliver data and power simultaneously to compatible devices such as IP cameras, wireless access points, and VoIP phones.

Designed for High-Density Network Environments

Engineered for professional networking applications, the patch cord provides excellent performance in data centers, telecommunications rooms, and enterprise network installations.

Product Specifications

• Product Name: R & M Patch Cord CU EL Cat6A AWG26 LSZH Grey 7m
• Model Number: R842755
• Cable Category: Cat6A Class EA
• Cable Type: U/UTP (Unshielded Twisted Pair)
• Cable Length: 7 m (Approximately 23 ft)
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Cable Color: Gray (RAL 7035)
• Conductor Type: AWG 26/7 Stranded Copper
• Number of Wires: 8
• Pair Configuration: 4 Twisted Pairs
• Cable Outer Diameter: Approximately 6.0 mm
• Connector Type: RJ45 Unshielded Plugs on Both Ends
• Contact Material: Bronze (CuSn6) with Gold Plating
• Contact Durability: Minimum 750 Mating Cycles
• Transmission Speed: Up to 10 Gbps
• Frequency Support: Up to 500 MHz
• Impedance: 100 Ohm
• Current Rating: Up to 1.5 A at 25°C
• PoE Support: IEEE 802.3af PoE, IEEE 802.3at PoE+, IEEE 802.3bt 4PPoE
• Minimum Bend Radius: 4x Cable Diameter
• Operating Temperature Range: -20°C to +60°C
• Standards Compliance: ISO/IEC 11801 Class EA, EN 50173-1, TIA/EIA 568.2-D
• Connector Standard: IEC 60603-7-41
