MikroTik CCR1009-7G-1C-1S PC Cloud Core Router with Passive Cooling

The new updated revision of CCR1009 is here. We attempted to combine all the customer feedback and best practice in CCR device manufacturing that we learned over the last three years, since the first CCR1009 devices were launched.

Important changes

No switch-chip – the device now features only fully independent Ethernet ports each with a direct connection to the CPU, allowing to overcome previous shared 1Gbit limitation from switch-chip ports and utilize full potential of CPU processing power on those ports.

Combo-port – a single 1Gbit software interface that has two hardware interfaces – an SFP cage and a Gigabit Ethernet port, allowing you to use any type of connection available to you. It is also possible to switch between both physical interfaces in RouterOS. In an event of disconnect the combo-port provides hardware fail-over feature.

100Mbps SFP support – this is our first device that supports 100BASE-LX/100BASE-SX/100BASE-BX fiber modules, as well as standard 1.25G SFP modules.

More throughput – because the ports are now directly connected to the CPU, the new CCR1009 can achieve even higher throughput.

This unit is equipped with passive cooling enclosure, two heat-pipes and a specially designed heat-sink, so its completely silent. It’s powered by an external 24V 2.5A AC/DC adapter and supports power redundancy if you also power it from the PoE input port.

Unit also includes a LCD touchscreen, smart card slot, microSD and a SFP+ port for 10G connections.

Product Features

• CPU: Tilera Tile-Gx8009 CPU (9-cores, 1Ghz per core)
• Memory: Built-in 2GB RAM
• Ethernet: 7x Gigabit Ethernet ports
• SFP: 1x SFP cage; 1x SFP cage
• OS: MikroTik RouterOS, Level6 license

MikroTik CCR1009-7G-1C-1S Specifications

DETAILS
Product code	CCR1009-7G-1C-1S+
Architecture	TILE
CPU	TLR4-00980
CPU core count	9
CPU nominal frequency	1.2 GHz
Dimensions	444x175x47mm
License level	6
Operating System	RouterOS
Size of RAM	2 GB
Storage size	128 MB
Storage type	NAND
Tested ambient temperature	-20C .. +60C

Powering

DETAILS
Max Power consumption	34W
PoE in	Passive PoE
PoE in input Voltage	15-57 V
Number of AC inputs	2
AC input range	100-240
Number of DC inputs	1 (PoE-IN)

Ethernet

DETAILS
10/100/1000 Ethernet ports	7
Ethernet Combo ports	1

Fiber

DETAILS
SFP+ ports	1

Peripherals

DETAILS
Number of SIM slots	1 Smart card (Mini SIM)
Serial port	RS232
Number of USB ports	1
USB Power Reset	Yes
USB slot type	microUSB type AB
Max USB current (A)	1

Other

DETAILS
CPU temperature monitor	Yes
Current Monitor	Yes
PCB temperature monitor	Yes
Voltage Monitor	Yes
