Giganet Category 6A Solid F/UTP Outdoor LDPE Cable (GN-C6A-F/UTP-LDPE)

The Giganet Category 6A Solid F/UTP Outdoor LDPE Cable (GN-C6A-F/UTP-LDPE) is a high-performance shielded Ethernet cable designed for outdoor 10 Gigabit networks. Featuring solid 23 AWG copper conductors and an overall foil shield, it provides superior protection against electromagnetic interference (EMI) and alien crosstalk, ensuring stable, high-speed data transmission. Its UV and moisture-resistant LDPE jacket makes it ideal for exposed or conduit-protected installations, including building-to-building links, surveillance networks, and campus environments. Compliant with industry standards, this cable combines reliability, durability, and future-proof network performance for professional and enterprise applications.

Product Features

Outdoor Durability

The LDPE jacket offers excellent resistance to UV rays, moisture, and extreme temperatures, making it suitable for direct burial, aerial, or exposed installations.

High-Speed 10 Gigabit Performance

Supports data rates up to 10 Gbps with a bandwidth of 500 MHz, delivering reliable performance for demanding Ethernet applications.

EMI and Crosstalk Protection

The F/UTP shielding with an overall foil screen and 24 AWG drain wire protects against external electromagnetic interference, ensuring consistent signal integrity.

Solid Conductor Reliability

Solid 23 AWG bare copper conductors provide superior conductivity and minimal signal loss over long distances compared to stranded alternatives.

Versatile Outdoor Applications

Ideal for outdoor backbone links, remote surveillance, building-to-building Ethernet connections, and installations in ducts, conduits, or on exposed walls.

Product Specifications

• Brand: Giganet
• Model Number: GN-C6A-F/UTP-LDPE
• Category: 6A (Cat 6A) F/UTP Shielded Outdoor Cable
• Conductor: 23 AWG solid bare copper
• Number of Pairs: 4 twisted pairs with varying lay lengths
• Insulation Material: Polyethylene (PE)
• Pair Separator: Central ‘X’ shaped polyethylene filler
• Shielding: Overall foil tape with 24 AWG drain wire
• Outer Jacket: LDPE, UV and moisture resistant
• Jacket Color: Black
• Cable Diameter: Approx. 7.5 mm ± 0.5 mm
• Standard Length: 305 meters (1000 ft) drum
• Frequency Bandwidth: Up to 500 MHz
• Maximum Data Rate: 10 Gbps (10GBASE-T Ethernet) up to 100 meters
• Impedance: 100 ± 15 ohms
• DC Resistance: <9.38 Ω/100m
• Operating Temperature Range: -20°C to +75°C
• Standards Compliance: ANSI/TIA-568.2-D, ISO/IEC 11801-1, EN 50173-1
• Ideal Applications: Outdoor network links, surveillance systems, building-to-building connections, conduit or exposed wall installations
