Ugreen USB C Triple Display Docking Station (12-in-1) UG-80551

The UGREEN USB‑C Triple Display Docking Station – 12‑in‑1 (UG‑80551) is a comprehensive hub designed for high‑productivity workstations. Featuring dual 4K HDMI and one VGA port, Thunderbolt 3 pass‑through, 60 W PD charging, gigabit Ethernet, and multiple USB ports (including USB‑C), it transforms a single USB‑C port into a powerful desktop workstation solution. With universal compatibility across Windows, macOS, and Linux systems, this docking station delivers seamless multi‑monitor setups, fast data transfer, and stable connectivity—all encased in a sleek aluminum design.

Product Features

triple monitor support

Drive dual displays at 4K @ 30 Hz via HDMI and a third at 1080p @ 60 Hz via VGA, enabling extended workspace across three screens.

60 W USB-C power delivery

Passes power from your charger to the host laptop or device while powering the dock and connected peripherals.

Gigabit Ethernet connection

Provides fast and reliable wired network access up to 1000 Mbps for stable streaming, file transfers, and low‑latency communication.

Multiple USB ports for peripherals

Includes two USB‑A 3.0 and two USB‑A 2.0 ports, plus one USB‑C 3.0 port, ideal for connecting drives, input devices, and accessories.

audio in/out and sd/micro-SD slots

Offers a 3.5 mm audio jack and SD plus micro‑SD card readers, perfect for audio streaming and quick media transfers.

sleek aluminum construction

Durable metal housing offers efficient heat dissipation and a premium aesthetic suited for modern workspaces.

plug‑and‑play compatibility

No driver installation required—instantly compatible with Windows, macOS, and Linux systems via a single USB‑C connection.

Product Specifications

• Model: UG‑80551
• Input Interface: USB‑C (supports DisplayPort Alt Mode and 60 W PD)
• Display Outputs:
  • 2 × HDMI (max 4K @ 30 Hz each
  • 1 × VGA (max 1080p @ 60 Hz)
• Power Delivery: Up to 60 W via USB‑C host pass‑through
• Ethernet: 1 × RJ45 gigabit (10/100/1000 Mbps)
• USB Ports:
  • 2 × USB‑A 3.0 (5 Gbps)
  • 2 × USB‑A 2.0
  • 1 × USB‑C 3.0 (5 Gbps)
• Audio Port: 3.5 mm headphone/microphone combo jack
• Card Readers: SD and micro‑SD slots (UHS‑I compatible)
• Operating Voltage: USB‑C PD up to 60 W
• Compatibility: Windows 7/8/10/11, macOS 10.12+, Linux
• Housing Material: Aluminum alloy
• Cable Length: 20 cm USB‑C integrated cable
• Dimensions: Approximately 140 × 70 × 25 mm
• Weight: Approx. 350 g
• Protection Features: Over-current, over-voltage, short-circuit, and over-temperature safeguards
