CUDY RE1200 AC1200 Wi-Fi Mesh Repeater (RE1200)

The CUDY RE1200 AC1200 Wi-Fi Mesh Repeater is designed to expand and strengthen existing wireless networks, providing seamless coverage for homes and small offices. Featuring dual-band Wi-Fi 5 with MU-MIMO support, the RE1200 delivers combined speeds of up to 1200 Mbps and can connect up to 30 devices simultaneously. With Cudy Mesh support, Ethernet backhaul, and app-based management, it allows effortless setup and reliable expansion of your Wi-Fi network without dead zones.

Product Features

Dual-Band AC1200 Wi-Fi

Supports 5 GHz speeds up to 867 Mbps and 2.4 GHz speeds up to 300 Mbps, providing fast and stable connections for streaming, online gaming, and general internet use.

Works with Any Wi-Fi Router

Compatible with any existing Wi-Fi router, allowing easy integration into current networks and instant extension of wireless coverage.

MU-MIMO and Multi-Band Backhaul

Supports MU-MIMO for efficient multi-device performance and multi-band simultaneous backhaul to maintain stable and high-speed connections between the mesh satellite and the main router.

Ethernet Backhaul Support

Equipped with one Fast Ethernet port for wired backhaul or connecting a wired device, offering flexible deployment and improved network reliability.

Cudy Mesh Satellite

Functions as part of a Cudy Mesh system, enabling multiple RE1200 units to be connected for seamless whole-home Wi-Fi coverage with minimal signal loss.

Plug-In Installation

Compact design allows direct plug-in to a power socket, making installation fast, convenient, and ideal for tight spaces.

App and Web-Based Management

Provides local and remote control through the Cudy App or web interface, allowing easy monitoring, configuration, firmware updates, and network diagnostics.

Product Specifications

• Model Version: RE1200 1.0
• Part Number: RE1200
• Wireless Standard: Wi-Fi 5 (802.11ac)
• Maximum Wi-Fi Speed:
  • 5 GHz: 867 Mbps
  • 2.4 GHz: 300 Mbps
• Wi-Fi Streams: 2T2R (2×2 MIMO) per band
• Antennas: 2 × fixed internal antennas
• MU-MIMO Support: 5 GHz
• Maximum Connected Devices: 30
• Ethernet Ports: 1 × 10/100 Mbps RJ45
• Operation Modes: Access Point, Range Extender
• Mesh Support: Cudy Mesh Satellite with wireless and wired backhaul
• Multi-Band Simultaneous Backhaul: Supported
• Wi-Fi Security: WPA/WPA2/WPA3
• WPS Support: Yes
• Power Input: AC 100–240V
• Operating Temperature: 0 °C to 40 °C
• Storage Temperature: -40 °C to 70 °C
• Operating Humidity: 10%–90% non-condensing
• Storage Humidity: 5%–95% non-condensing
• Installation Type: Plug-in-socket
• Dimensions: 129.6 × 80 × 48.6 mm
• Net Weight: UK: 210 g, US/EU: 205 g
• Package Contents: RE1200 Wi-Fi Mesh Repeater, installation guide
