Dahua 512GB 2.5-Inch SATA III Solid State Drive (DHI-SSD-E800S512G)

The Dahua DHI-SSD-E800S512G is a high-capacity 512GB 2.5-inch SATA III internal solid-state drive designed to deliver fast, stable, and energy-efficient performance for laptops, desktop PCs, and surveillance systems. Built with advanced 3D NAND flash and a professional-grade controller, this SSD significantly improves boot times, application loading, and overall system responsiveness compared to traditional hard drives, making it a reliable storage upgrade for both consumer and commercial use.

Product Features

High-Speed SATA III Performance

Utilizing a SATA III 6Gb/s interface, the Dahua E800S 512GB SSD delivers sequential read speeds of up to 560 MB/s and write speeds of up to 510 MB/s. This high-speed performance ensures smoother multitasking, faster file transfers, and reduced system latency.

Advanced 3D NAND Flash Technology

The drive is built with 3D TLC NAND flash memory, which enhances durability, data integrity, and storage efficiency. This technology provides consistent performance and improved endurance for long-term use.

Optimized Performance with SLC Cache

An integrated high-performance SLC cache accelerates read and write operations, delivering faster response times during intensive workloads and frequent data access.

Intelligent Drive Management and Monitoring

Support for S.M.A.R.T., TRIM, NCQ, and garbage collection helps maintain sustained performance and allows users to monitor drive health and status, extending the overall lifespan of the SSD.

Durable and Reliable Solid-State Design

With no moving parts, the Dahua E800S SSD offers excellent resistance to shock and vibration. Its robust construction makes it suitable for demanding environments, including continuous-operation systems such as surveillance setups.

Energy-Efficient Operation

Designed for low power consumption, this SSD helps reduce heat output and energy usage, contributing to quieter operation and extended battery life in laptops.

Product Specifications

• Capacity: 512 GB
• Form Factor: 2.5-inch (7 mm thickness)
• Interface: SATA III 6 Gb/s
• Flash Memory Type: 3D TLC NAND
• Sequential Read Speed: Up to 560 MB/s
• Sequential Write Speed: Up to 510 MB/s
• 4K Random Read IOPS: Up to 52,000
• 4K Random Write IOPS: Up to 59,000
• Endurance Rating: 200 TBW
• MTBF: 1,500,000 hours
• Power Consumption: Max 1300 mW, Idle 415 mW
• Shock Resistance: 1500 G / 0.5 ms
• Vibration Resistance: 10–1000 Hz at 2.78 G
• Operating Temperature: 0°C to 70°C
• Storage Temperature: –40°C to 85°C
• Operating Humidity: 5% to 95% non-condensing
• Dimensions: 100.20 mm × 69.90 mm × 7.00 mm
• Weight: Up to 40 g
