Shield R13X 3kVA 2.7kW Online Double-Conversion Rack/Tower UPS

The Shield R13X 3kVA 2.7kW Online Double-Conversion UPS is a professional-grade power protection solution engineered for business-critical IT infrastructure, telecommunications systems, server environments and networking applications. Built under the Shield R1 Series, the R13X utilizes true online double-conversion technology to provide continuous power conditioning and complete electrical isolation from utility power disturbances.

With a 3kVA / 2.7kW capacity and a high 0.9 output power factor, the Shield R13X delivers significantly more usable power than conventional UPS systems while maintaining stable, pure sine wave output. Its flexible rack/tower deployment options, intelligent monitoring system and scalable battery architecture make it an ideal UPS solution for organizations that require dependable backup power and long-term reliability.

Browse our complete range of UPS Power Backup Systems in Kenya, explore our selection of Shield UPS Systems in Kenya, discover more products from the Shield Online Store in Kenya, or view our UPS Power Backup Services and Solutions in Kenya together with dedicated Shield UPS Power Backup Solutions in Kenya for professional UPS sizing, installation, maintenance, battery replacement and power backup support.

Shield R13X 3kVA Online Double-Conversion UPS Features in Kenya

True Online Double-Conversion Technology

The Shield R13Xi continuously converts utility power through AC-to-DC and DC-to-AC stages, ensuring complete isolation from voltage fluctuations, surges, spikes and power interruptions.

3kVA / 2.7kW Output Capacity

With a high 0.9 output power factor, the UPS delivers 2.7kW of active output power, providing greater usable capacity for connected equipment.

Pure Sine Wave Output

Provides high-quality pure sine wave power suitable for servers, telecommunications systems, networking devices and sensitive electronic equipment.

Zero Transfer Time Operation

The online double-conversion architecture delivers 0ms transfer time, ensuring uninterrupted operation during utility power failures and fluctuations.

Flexible Rack/Tower Configuration

The dual-purpose chassis allows deployment as a standard rackmount UPS or a standalone tower unit using the supplied mounting accessories.

Massive Runtime Scalability

Supports up to eight external battery modules, enabling organizations to significantly extend backup runtime during prolonged power outages.

Intelligent Battery Management

The smart charging system optimizes charging cycles and battery performance to maximize service life and maintain operational readiness.

Advanced System Protection

Comprehensive protection mechanisms safeguard connected equipment against overvoltage conditions, short circuits, thermal overload events and electrical disturbances.

LCD and LED Diagnostic Interface

The integrated LCD and LED monitoring system provides real-time visibility of load levels, battery conditions, alarms and operational status.

High Operating Efficiency

The energy-efficient design achieves operating efficiency greater than 95.5%, helping reduce energy consumption and operating costs.

Advanced Communication Interfaces

Built-in USB and RS232 communication ports provide flexible integration with monitoring software and infrastructure management systems.

Optional SNMP Network Monitoring

The integrated expansion slot supports optional SNMP network cards for centralized monitoring, remote diagnostics and UPS management.

Shield R13X 3kVA Online Double-Conversion UPS Specifications

• Brand: Shield
• Model: R13Xi
• Series: Shield R1 Series
• UPS Topology: Online Double Conversion
• Capacity: 3kVA / 2.7kW
• Output Power Factor: 0.9
• Input Voltage Range: 110VAC to 288VAC
• Input Frequency Range: 40Hz to 70Hz Auto-Sensing
• Input Power Factor: Greater Than 0.99
• Output Voltage Regulation: ±1%
• Output Waveform: Pure Sine Wave
• Output THDu: Less Than 1% Linear Load
• Output THDu: Less Than 5.5% Non-Linear Load
• System Efficiency: Greater Than 95.5%
• Output Receptacles: IEC C13 and IEC C19
• Display: LCD and LED Monitoring Interface
• Communication Ports: USB and RS232
• Network Management: Optional SNMP Card
• Battery Expansion: Up to 8 External Battery Modules
• Operating Temperature: 0°C to 40°C
• Relative Humidity: 0% to 95% Non-Condensing

Applications of Shield R13X 3kVA Online Double-Conversion UPS

• Small and medium-sized data centers
• Server and storage systems
• Network switches and routers
• Telecommunications infrastructure
• CCTV and security systems
• Business-critical workstations
• Network cabinets and IT rooms
• Mission-critical electronic equipment

Buy Shield R13X 3kVA Online Double-Conversion UPS in Kenya

Buy the Shield R13X 3kVA 2.7kW Online Double-Conversion UPS from Rapidtech Networks Limited at the best price in Kenya. We supply genuine Shield UPS systems designed for networking, servers, telecommunications and business continuity applications.

We offer fast countrywide delivery to Nairobi, Mombasa, Kisumu, Nakuru, Eldoret, Thika, Kiambu, Machakos, Nyeri, Meru, Embu, Kakamega, Kisii, Kitale, Naivasha, Kericho, Bungoma, Garissa, Malindi and other towns throughout Kenya.

Our technical team provides UPS sizing, installation, commissioning, preventive maintenance, battery replacement services and after-sales technical support to ensure maximum system uptime and long-term reliability.
