TP-Link 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+ (TL-SF1006P)

The TP-Link 6-Port 10/100Mbps Desktop Switch with 4-Port PoE+ (TL-SF1006P) is a compact and efficient unmanaged PoE switch designed for small offices, IP surveillance systems, and home networks. Equipped with four PoE+ ports and a total power budget of up to 67 W, it delivers both data and power over Ethernet to compatible devices such as IP cameras, wireless access points, and VoIP phones. With long-range PoE transmission up to 250 meters, priority mode for critical applications, and plug-and-play operation, the TL-SF1006P provides stable, secure, and easy network expansion without configuration.

Product Features

Power over Ethernet Plus Support

Four PoE+ ports support IEEE 802.3af/at standards, delivering up to 30 W per port to power compatible network devices through a single Ethernet cable.

Long-Range PoE Transmission

Extend Mode enables data and power transmission distances of up to 250 meters, making it suitable for large-area deployments such as warehouses and outdoor surveillance.

Priority Mode for Critical Devices

Priority Mode assigns higher priority to ports 1 and 2, ensuring stable performance for latency-sensitive applications like security cameras and voice systems.

PoE Auto Recovery

Automatically detects and reboots unresponsive PoE-powered devices, reducing downtime and minimizing the need for manual intervention.

Reliable and Silent Operation

Fanless design ensures quiet operation, while store-and-forward switching and flow control help maintain reliable data transmission.

Plug and Play Design

Unmanaged setup allows instant deployment with no configuration required, saving time and simplifying installation.

Product Specifications

• Ports: 6 × 10/100 Mbps RJ45 ports
• PoE Ports: 4 × PoE+ ports (Ports 1–4)
• PoE Standard: IEEE 802.3af/at compliant
• Total PoE Power Budget: Up to 67 W
• Maximum PoE Output: Up to 30 W per PoE port
• Switching Capacity: 1.2 Gbps
• Packet Forwarding Rate: 0.8928 Mpps
• MAC Address Table: 2K
• Jumbo Frame Support: 2 KB
• Transmission Method: Store-and-Forward
• Network Media:
  • 10BASE-T: UTP Category 3, 4, 5 (up to 100 m)
  • 100BASE-TX: UTP Category 5/5e (up to 100 m)
• Flow Control: IEEE 802.3x for Full Duplex, Backpressure for Half Duplex
• Fan Quantity: Fanless
• Physical Security Lock: Yes
• Power Supply: External power adapter, 53.5 V DC / 1.31 A
• Maximum Power Consumption:
  • 2.52 W (no PD connected)
  • 75.4 W (with 67 W PD connected)
• Maximum Heat Dissipation:
  • 8.59 BTU/h (no PD connected)
  • 257.11 BTU/h (with 67 W PD connected)
• Certifications: FCC, CE, RoHS
• Dimensions (W × D × H): 6.2 × 4.0 × 1.0 in (158 × 101 × 25 mm)
• Operating Temperature: 0°C to 40°C
• Storage Temperature: -40°C to 70°C
• Operating Humidity: 10% to 90% RH non-condensing
• Storage Humidity: 5% to 90% RH non-condensing
• Package Contents:
  • TP-Link TL-SF1006P Desktop Switch
  • Power Adapter
  • Installation Guide
