Hikvision NKS422W03H Wi-Fi NVS Kit with PT Dome Camera

The Hikvision NKS422W03H Wi-Fi NVS Kit with PT Dome Camera is a comprehensive surveillance solution designed for seamless security monitoring in homes, offices, and businesses. This kit includes a high-performance PT (Pan-Tilt) dome camera and a Network Video Storage (NVS) unit, offering wireless connectivity and easy installation. With its high-definition video recording, motion detection, and smart alerts, this system ensures round-the-clock security. Ideal for both indoor and outdoor applications, it provides a reliable and user-friendly security solution.

Product Features

High-Definition PT Dome Camera

The included PT dome camera captures crisp 1080p Full HD video, delivering clear and detailed footage for effective surveillance.

Wi-Fi Connectivity for Wireless Setup

With built-in Wi-Fi, the camera and NVS unit connect seamlessly without the need for extensive wiring, making installation quick and hassle-free.

Pan-Tilt Function for Full Coverage

The PT functionality allows the camera to pan and tilt, providing a wide-angle view and eliminating blind spots for complete area coverage.

Smart Motion Detection & Alerts

Equipped with intelligent motion detection, the system instantly notifies users of any suspicious activity, ensuring timely action.

Infrared Night Vision for 24/7 Security

The advanced IR night vision technology ensures clear footage in low-light or complete darkness, maintaining visibility up to 30 meters.

NVS Unit for Secure Video Storage

The Network Video Storage (NVS) unit allows for local recording and playback, offering a secure storage solution without relying on cloud services.

Two-Way Audio for Real-Time Interaction

The built-in microphone and speaker enable two-way communication, allowing users to speak with visitors or warn potential intruders.

Weatherproof Design for Outdoor Use

With an IP-rated weatherproof enclosure, the camera is built to withstand harsh weather conditions, making it suitable for both indoor and outdoor environments.

Applications

• Home Security: Provides comprehensive security coverage for homes and apartments.
• Small Businesses: Ideal for small businesses such as retail stores, offices, and restaurants

  Rental Properties: Monitors rental properties for security and tenant safety.

Product Specifications

Camera

• Camera Case TypeBullet;Dome
• Image Sensor1/3″ Progressive Scan CMOS
• Min. Illumination

  Bullet：Color: 0.01 Lux @ (F2.0, AGC ON),B/W: 0 Lux with IR

  Dome：Color: 0.04 Lux @ (F2.0, AGC ON),B/W: 0.01 Lux @ (F2.0, AGC ON),0 Lux with IR

• Day &NightIR cut filter
• WDRDWDR
• Angle Adjustment

  Bullet: Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°

  Dome: Pan: 0° to 345°,tilt: 0° to 80°

• Protection LevelIP66
• Wi-Fi SupportYes

Camera/Lens

• Focal Length2.8 mm
• ApertureF2.0
• FocusFixed
• FOVHorizontal FOV 101°, vertical FOV 56°, diagonal FOV 118°

Camera/IR

• IR Range

  Bullet：Up to 30 m

  Dome：White light distance: up to 25 m,IR distance: up to 25 m

• Camera/Compression Standard
• Video CompressionH.265;H.264;MJPEG
• H.264 TypeBaseline Profile/Main Profile/High Profile
• H.265 TypeMain Profile
• Video Bit Rate32 Kbps to 8 Mbps
• Audio CompressionG.711/AAC-LC
• Audio Bit Rate64 Kbps (G.711ulaw)/16 to 64 Kbps (AAC-LC)
• Audio Sampling Rate8 kHz/16 kHz
• Environment Noise FilteringYes

Camera/Image

• Max. Resolution2MP
• Main Stream

  50 Hz: 25 fps (1920 × 1080, 1280 × 720, 768 x 432)

  60 Hz: 30 fps (1920 × 1080, 1280 × 720, 768 x 432)

• Sub-stream

  50 Hz: 25 fps (768 × 432)

  60 Hz: 30 fps (768 × 432)

• Image SettingSaturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
• Day/Night SwitchAuto/Scheduled/Day/Night

Camera/Network

• Alarm TriggerMotion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception
• ProtocolsTCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTCP, RTSP, NTP, IGMP, IPv6, UDP, QoS, UPnP
• General FunctionOne-key reset, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter

Camera/Interface

• Communication Interface1 RJ45 10M/100M self-adaptive Ethernet port
• Reset ButtonYes

Camera/General

• Power Supply

  Bullet: 12 VDC ± 25%, 0.5 A, max. 6 W,Ø5.5 mm coaxial power plug,reverse polarity protection,A switching adapter is included in the package.

  Dome: 12 VDC ± 25%, reverse polarity protection, 0.75 A, max. 9 W, Ø5.5 mm coaxial power plug

• Consumption

  Bullet: ≤ 6 W

  Dome: ≤ 9 W

• Working Temperature

  Bullet: -30 °C to 60 °C (-22 °F to 140 °F)

  Dome: -10 °C to 40 °C (-14 °F to 104 °F)

• Working Humidity95% or less (non-condensing)
• Dimension (W × D × H)

  Bullet: 260.9 mm × 113.9 mm × 67.4 mm (10.3″ × 4.5\” × 2.7\”)

  Dome: Ø124 mm × 119 mm (Ø4.89 × 4.68\”)”

• Weight

  Bullet: 305 g (0.67 lb.)

  Dome: 600 g (1.32 lb.)

NVR/Video and Audio

• IP Video Input4-ch
• Incoming/Outgoing Bandwidth20 Mbps/20 Mbps

NVR/Decoding

• Video Resolution6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
• Synchronous Playback1-ch

NVR/Network

• Network Interface1, RJ45 10/100M Ethernet interface

NVR/Wi-Fi

• Frequency Band2.4 GHz
• Antenna StructureHigh gain antenna
• Transmission Speed150 Mbps
• Transmission StandardIEEE 802.11b/g/n/ax

NVR/Auxiliary Interface

• SD Card32G/64G/128G/256G/512G

NVR/General

• Power Supply12 VDC
• Consumption (without HDD and PoE off)≤ 6 W
• Working Temperature-10 °C to 55 °C (14 °F to 131 °F)
• Working Humidity10% to 90%
• Dimension (W × D × H)163 x 125 x 26 mm (6.4″ × 4.9″ × 1.0″)
• Weight (without hard disk)≤ 500g

Kit

• Accessories

  Power adaptor: 2 × IPC power adaptor, 1 × NVS power adaptor

  Ethernet cable: RJ45, Cat5e UTP, 1 m

• CertificationCB, CE
• Weight (with package)≤ 2.5 kg (5.5 lb)
